General Specifications
| Item | Specification |
| Model | X6S KV160 |
| Max Thrust | 11.9 kg |
| Recommended Takeoff Weight per Rotor | 3.5–5.5 kg |
| Lithium Compatible | 12–14S (LiPo) |
| Operating Temperature | -20°C to 50°C |
| Total Weight | 700 ± 10 g |
| IP Rating | IPX6 |
| Tube Diameter | 30 mm |
| Power Wire | 12 AWG Black Wire (Line Length: 900 ± 10 mm) |
| Signal Wire | Shielded / Teflon Cable (Line Length: 1000 ± 10 mm) |
Motor Specifications
| Item | Specification |
| Diameter / Pitch | 64 × 15 mm |
| Motor Weight | 340 g |
Propeller Specifications
| Item | Specification |
| Stator Size | 24 × 8.0 (Folding) |
| Propeller Weight | 100 g / set |
ESC Specifications
| Item | Specification |
| Max Voltage | 61 V |
| Max Current (Transient / Continuous) | 80 A |
| Working Pulse Width | 1050–1950 μs |
| Max Signal Frequency | 50–500 Hz |
Battery Requirement
| Item | Specification |
| Battery Type | 12–14S (LiPo) |
