| Item | Value |
| KV | 300 |
| Shaft | Steel shaft |
| Bearing | 8×16×5 |
| Shaft Diameter | 6 mm |
| Excluding weight of silicone wire | 277.4 g |
| Configuration | 12N14P |
| Stator | Kawasaki 0.2 |
| Magnet | N52SH (Curved Magnet) |
| Motor Cable | 14#, 400 mm |
| Weight with silicone wire | 308.9 g |
Test Report (ZT1-4720)
Propeller: FZ 1507-3 | Temperature: 57°
| Throttle | RPM | Thrust (g) | Voltage (V) | Current (A) | Power (W) | Efficiency (g/W) |
| 20% | 1460.6 | 600 | 25.77 | 0.733 | 18.88941 | 31.7638 |
| 40% | 2755.7 | 1260 | 25.77 | 3.458 | 89.11266 | 14.1394 |
| 60% | 3926.5 | 2140 | 25.68 | 9.474 | 243.29232 | 8.7960 |
| 80% | 4972.1 | 3200 | 25.37 | 19.525 | 495.34925 | 6.4601 |
| 100% | 5889.6 | 4330 | 25.18 | 33.386 | 840.65948 | 5.1507 |
Propeller: FZ 1507-3 | Temperature: 59°
| Throttle | RPM | Thrust (g) | Voltage (V) | Current (A) | Power (W) | Efficiency (g/W) |
| 20% | 1854.8 | 770 | 32.86 | 1.019 | 33.48434 | 22.9958 |
| 40% | 3413.4 | 1710 | 32.85 | 4.996 | 164.1186 | 10.4193 |
| 60% | 4822.9 | 3050 | 32.6 | 14.032 | 457.4432 | 6.6675 |
| 80% | 6028.1 | 4550 | 32.3 | 28.585 | 923.2955 | 4.9280 |
| 100% | 7070.9 | 6130 | 31.98 | 49.152 | 1571.88096 | 3.8998 |
Specifications (ZT1-4720) KV380
| Item | Value |
| KV | 380 |
| Shaft | Steel shaft |
| Bearing | 8×16×5 |
| Shaft Diameter | 6 mm |
| Excluding weight of silicone wire | 286.3 g |
| Configuration | 12N14P |
| Stator | Kawasaki 0.2 |
| Magnet | N52SH (Curved Magnet) |
| Motor Cable | 14#, 400 mm |
| Weight with silicone wire | 317.8 g |
Propeller: FZ 1507-3 | Temperature: 65°
| Throttle | RPM | Thrust (g) | Voltage (V) | Current (A) | Power (W) | Efficiency (g/W) |
| 20% | 932.3 | 750 | 25.77 | 1.349 | 34.76373 | 21.5742 |
| 40% | 1695.1 | 1670 | 25.8 | 6.436 | 166.0488 | 10.0573 |
| 60% | 2398.5 | 2930 | 25.5 | 17.863 | 455.5065 | 6.4324 |
| 80% | 3007.9 | 4370 | 25.28 | 37.687 | 952.72736 | 4.5868 |
| 100% | 3497.5 | 5770 | 24.79 | 63.242 | 1567.76918 | 3.6804 |
Propeller: FZ 1507-3 | Temperature: 70°
| Throttle | RPM | Thrust (g) | Voltage (V) | Current (A) | Power (W) | Efficiency (g/W) |
| 20% | 1166.7 | 960 | 32.87 | 1.873 | 61.56551 | 15.5931 |
| 40% | 2124.5 | 2420 | 32.65 | 9.624 | 314.2236 | 7.7015 |
| 60% | 2945.8 | 4250 | 32.36 | 26.827 | 868.12172 | 4.8956 |
| 80% | 3605.4 | 6000 | 31.89 | 54.701 | 1744.1489 | 3.4395 |
| 100% | 4029.8 | 7700 | 31.19 | 90.403 | 2819.66957 | 2.7308 |
